½" CPVC Socket Stub Out Elbow with Square Mounting Flange, 3-1/2" x 8"

• Connects to CPVC tubing (Solvent Weld)
• Closed end for pressure testing
• Flange for nailing to a stud
• cUPC approved for use in USA and Canada
• Meets ASTM D2846, CSA B137.6
• ASTM B88 type L copper tube
• Complies with Section 1417(d) of the Safe Drinking Water Act, the lead content requirements of Section 116875 of the California Health & Safety Code, and NSF/ANSI 372-2016

Country of Origin:China

Material:Copper

Size:1/2"

Prop65 Warning:Cancer and Reproductive Harm – www.P65Warnings.ca.gov

Length:3-1/2" x 8"

AB100 Certified:N/A

CEC Listed:No

cUPC Listed:Yes

UPC Listed:Yes

End Connections:End Connections:Male CPVCCTS (Spun Closed For Testing)

ANSI Standard:ANSI Standard:ANSI 372-2016ANSI 61-2018

ASTM Standard:ASTM D2846-2019a

CEC Compliant:No

IAPMO Listed:Yes

Lead Law Compliant:Yes

MASS Approved:Yes

NSF Certified:No

NSF Standard:NSF Standard:NSF 372-2016NSF 61-2018

SDWA Compliant:Yes

HAZMAT:No

CAN Standard:CAN 61-2018
